Description
EU / US – price incl. VAT
Because it is a super large product and super power battery, the delivery takes about 45days.
Product Specification（16S）
Nominal voltage : 51.2V(15S)
Nominal capacity : 302Ah@0.2C
Battery power : 15360Wh
Internal resistance: ≤100mΩ
Cycle life： 6000times
Self discharge： ≤3.5%（every month@25°C）
Charging voltage： 51.2-58.4V
Charging cut-off voltage: 58.4V
Standard discharge current:: 40A
Maximum sustained discharge：200A
Maximum pulse current： 300A（＜30S）
Standard charging current: 40A
Maximum continuous charging current 200A
Maximum discharge power： 5000W
Charging temperature ：0°C to 45°C
Discharge temperature: -20°C to 60°C
Dustproof and waterproof rating: IP55
Shell material: SPCC
Size: 520x300x900mm
Weight： 131KG
Packing weight: 149KG
Communication Ports : RS485*3/CAN/RS232
Packing list: screws, parallel power cable, mechanical support. Battery pack
Comatible Inverter Brands: Growatt, Goodwe, SofarSolar, Deye, Voltronic, Victron, SRNE…
Warrantty: 10 years Life, 7 years Warranty AH
Product Specification（15S）
Nominal voltage : 48.0V(15S)
Nominal capacity : 302Ah@0.2C
Battery power : 14400Wh
Internal resistance: ≤100mΩ
Cycle life： 6000times
Self discharge： ≤3.5%（every month@25°C）
Charging voltage： 53.2-54V
Charging cut-off voltage: 54.75V
Standard discharge current:: 40A
Maximum sustained discharge：200A
Maximum pulse current： 300A（＜30S）
Standard charging current: 40A
Maximum continuous charging current 200A
Maximum discharge power： 5000W
Charging temperature ：0°C to 45°C
Discharge temperature: -20°C to 60°C
Dustproof and waterproof rating: IP55
Shell material: SPCC
Size: 520x300x900mm
Weight： 125KG
Packing weight: 143KG
Communication Ports : RS485*3/CAN/RS232
Packing list: screws, parallel power cable, mechanical support. Battery pack
Comatible Inverter Brands: Growatt, Goodwe, SofarSolar, Deye, Voltronic, Victron, SRNE…
Warrantty: 10 years Life, 7 years Warranty AH
NOTICE
1,Do not immerse the battery in water or allow it to get wet.
2.Do not use or store the battery where is exposed to extremely hot.
3.Do not use battery in the strong electrostatic and magnetic field, otherwise probably the battery safety.
4.Do not reverse the positive (+) and negative (-) terminals，prevent reverse connection.
5.Charge with specified charge according to charging requirement.
6. Please use the connection between inverter and MPPT correctly.
